ITS Lens KM1614MP12C 16mm 12MP Manual Iris Lens, 1.1-inch F1.4 Fixed focus C Mount Traffic camera lens

FH至尊

ITS Lens KM1614MP12C 16mm 12MP Manual Iris Lens, 1.1-inch F1.4 Fixed focus C Mount Traffic camera lens: C-Mount f=16mm F1.4; Maximum image circle of 1.1"; High quality imaging with 12 MP resolution; high contrast,delivers clean and sharp images; Low distortion,Excellent low-light performance; Locking set screws for focus and Iris

Tel:+86 020-38312466

Specifications Dimension PDF download Other

Model		KM1614MP12C
Image Size		1.1-inch
Focal length		16mm
F?No.		F1.4-C
M.O.D(m)		0.3
Operation	Iris	Manual
	Focus	Manual
Horizontal Angle of View	1.1" Type	59.2°×46.2°×33.6°
	1" Type	54.1°×48.1°×25.9°
	2/3"Type	39.2°×31.5°×23.7°
Distortion	1.1" Type	2.35%
BFL		13.863mm
MFL		12.2mm
Flange BFL		17.526mm
Mount		C-Mount
Dimension		Ф43x69mm
Weight		253.0g
Operating temperature		-30℃～+70℃
Remark		12 Megapixel ITS Lens

Product Features
◆ Brand：ZLKC
◆ Image Size：1.1″ C-mount
◆ Focal length：f=16mm
◆ F No.：F1.4-C
◆ Features：1.1-inch ITS Lens 16mm 12MP Manual Iris Lens,? F1.4 C Mount Traffic camera lens

Model
KM1614MP12C

Dimension
FH至尊(中国)有限公司官网

Industries Application
These are used in video surveillance industry and ITS. Violation behaviors detection: driving on lane line, Illegal lane change, wrong-way driving detection, seatbelt and phone call detectionThese cover applications from ITS and road monitoring and bank to security bayonet monitoring, Electronic police snapshot and traffic cameras and so on
